Initial Operation

Initial Operation
i
Initializing starts after the voltage supply has been
switched on. The measuring system is ready for
use after approx. 10 seconds. To ensure precise
measurements, let the measuring system warm up
for approx. 60 minutes.
The controller is factory set to the static IP address
169.254.168.150. Use this address for a direct connec-
tion with a browser.
The start screen of the controller software is displayed in
the web browser now.
You can check the IP address of the controller, that are
connected to a PC / network, with the sensorTOOL.
exe program. This program is available online at
www.micro-epsilon.com/download/software/sensor-
TOOL.exe.
IMS5x00
Start the program sensorTOOL and click the button
.
Click the Open Website button to connect the con-
troller to your default browser.

Select a Sensor

Change to the Settings > Sensor menu.
Select a sensor from
the list.

Start of Measuring Range, Working Distance

A offset distance (SMR) or working distance between each
sensor and the target must be kept.
Distance sensor
https://
Thickness sensor
MR
Measurement
SMR
object
Operating range
Working distance
