Initial Operation

Signal Quality

Using the Signal quality function, you can influence the measuring rate and the respective averaging.
Averaging with the Median function is specified by the preset.
The subsequent moving averaging is specified by the Signal quality function.
Individual material selection is possible in the Settings > Data recording > Material selection menu.
IMS5x00
Averaging
Static
Moving with 128 vlues
Measuring rate 0.2 kHz
Balanced
Moving with 16 values
Measuring rate 1 kHz
Dynamic
Moving with 4 values
Measuring rate 6 kHz
Description
In the signal quality section, you can switch be-
tween three basic settings (static, balanced and
dynamic). The reaction in the chart and system
configuration is immediately visible.
i
If the controller starts up with a user-
defined measurement setting (setup), see
Chap. 6.10, the signal quality cannot be
changed.
