Button Multifunction - MICRO-EPSILON interferoMETER IMS5400-DS19 Quick Manual

LEDs Controller

Button Multifunction

The Multifunction button of the controller has multiple functions. It enables, e.g., to operate the light source.
The button is factory-set to the Pilotlaser on/off feature.
Key function
1 / 2
There are two defined time intervals for pressing the button; each of these can be assigned a function. All time inter-
vals are indicated by the LEDs flashing/lighting up.
Function 1
Master value
Pilot laser
SLED
0 2 sec
flashes off
slowly
IMS5x00
Set / reset
Starts or stops the master measurement of the selected signals
master value
Pilot laser Turns on/off the pilot laser
SLED Turns the light source on/off for the sensor
Inactive Key has no function
Function 2
5 sec 10 sec
flashes both
slowly off
Factory
setting
15 sec x min time
green off both on
on
Key
lock
The Intensity and Range
LEDs indicate the current-
ly selected function.
Multifunction Button
Actuation Time
