6.4 Electrical Specifications
DANGER!
Danger to life due to electric shock!
► Ensure that maintenance and service of electrical parts are performed only by qualified personnel if the bed is
connected.
Input Voltage
Maximum Power Input
Ingress Protection
Safety Class
Electrical Motor Duty Cycle
Accumulator
Fuse
Version 1
Version 2
Version 3
NOTE Upon request, LINET® can deliver hospital beds with electrical specifications that comply with regional standards (custom
voltage, different mains plugs).

6.5 Electromagnetic compatibility

Bed is intended for hospitals except for near active HF surgical equipment and the RF shielded room of a medical system for mag-
netic resonance imaging, where the intensity of EM disturbances is high.
Bed has defined no essential performance.
WARNING!
It is recommended to avoid the use of this device next to or in block with other device, because it could lead to
improper operation. If such use is needed, this device and the other equipment should be under surveillance
to verify proper operation.
List of used cables:
1. Mains cable, maximum length 6 m
2. ACP Attendant Control Panel, maximum length 3m
3. Handset, maximum length 3m
WARNING!
Use of the accessories, converters and other cables, than specified and provided by manufacturer of this bed
could lead to increase of electromagnetic emission or lower the electromagnetic immunity of this bed and lead
to improper operation.
WARNING!
Mobile RF communication device (including end use devices like antenna cables and external antenna) should
not be used closer than 30 cm (12 inches) from any part of this Image 3 B bed, including cables specified by
manufacturer. Otherwise this could lead to deterioration of functionality of this bed.
WARNING!
Do not overload the bed (SWL), respect the duty cycle (INT.) and consider chapter 18 Maintenance in order to
maintain the basic safety with regard to electromagnetic disturbances for the expected service life.
20
Parameter
230 V AC, 50/60 Hz
100 V AC, 50/60 Hz
110 V AC, 50/60 Hz
120 V AC, 50/60 Hz
127 V AC, 50/60 Hz
110-127 V AC, 50/60 Hz or 230 V AC, 50/60 Hz
370 VA
IP X4
Class I (with type B Applied Parts)
max. 2 minutes ON / 18 minutes OFF
Pb ACCU 2 x 12 V / 1,2 Ah / Fuse 15A
2x T1.6A L 250 V for 230 V version
2x T3.15A L 250 V for 100-127 V version
2x T1.6A L 250 V for 230 V version / 2x T3.15A L 250 V for
100-127 V version
Value
