5.4 Environment Conditions

Use Conditions
Ambient Temperature
Relative Humidity
Atmospheric Pressure
Storage and Transport Conditions
Ambient Temperature
Relative Humidity
Atmospheric Pressure
5.5 Electrical Specifications (Multicare LE)
Input Voltage
Version 1
Version 2
Version 3
Version 4
Version 5
Version 6
Maximum Power Input
Ingress Protection
Safety Class
Electrical Motor Duty Cycle
Accumulator
Fuse
Version 1
Version 2
ERGOFRAME
®
Ergoframe is the kinematic system of Backrest and Thighrest Adjustment resulting in extension of the Mattress support platform in
the seat section.
®
Ergoframe enlarges the space for pelvic area during Auto-contour. Because of increasement of the space the force applied results
in decrease of the pressure that can cause pressure injuries in the pelvic area.
Ergoframe maintains a stable ergonomic position of the body and spine of the patient, thus limiting unwanted movement of the pa-
tient by moving down or up in beds. Unified movement eliminates the patient's shift over the mattress and thus maintains a uniform
position of the patient's body that is not bound to the position of the bed parts.
D9U001MC5-0101_08
Parameter
10°C – 40°C
30% – 75 %
795 hPa – 1060 hPa
-20°C – 50°C
20% – 90 %
795 hPa – 1060 hPa
230 V AC, 50/60 Hz
100 V AC, 50/60 Hz
110 V AC, 50/60 Hz
120 V AC, 50/60 Hz
127 V AC, 50/60 Hz
110-127 V AC, 50/60 Hz or 230 V AC, 50/60 Hz
max. 370 VA
IPX4
Class I (with type B applied parts)
max. 2 min ON / 18 min OFF
Pb ACCU 2 x 12 V / 1,2 Ah / Fuse 15A
2x T2.0A L 250 V for 230 V version
2x T4.0A L 250 V for 100-127 V version
Value
