Sprint 200 WITH 2-PART MATTRESS SUPPORT PLATFORM
External Dimensions in Standard Stretcher Position (length x width)
Maximum Siderail Height above Mattress Support Platform
Siderail Length (Side Protection Zone for Patient)
Distance between siderail bars
Mattress dimensions (length x width)
Castor diameter
FlexiDrive Castor diameter
i-Drive Power Wheel diameter
Clearance of Undercarriage in Standard Position
Minimum — Maximum Mattress Support Platform Height above floor (wit-
hout Mattress)
Maximum Backrest Angle
Maximum Thighrest Angle
Maximum Calfrest Angle
Trendelenburg Tilt Angle / Anti-Trendelenburg Tilt Angle
Maximum Angle between Calfrest and Thighrest
Average Stretcher Weight of the Sprint 200 without i-Drive Power
Average Stretcher Weight of the Sprint 200 with i-Drive Power
SWL (Stretcher Safe Working Load)
Maximum Patient Weight
Maximum Mass of Mobile Hospital Bed (Maximum Mass of Empty Stret-
cher without i-Drive Power + Safe Working Load)
Maximum Mass of Mobile Hospital Bed (Maximum Mass of Empty Stret-
cher with i-Drive Power + Safe Working Load)
Ergoframe Distances (Backrest Distance/Thighrest Distance)
Maximum Sound Pressure Level
6.3 Electrical Specifications (only Sprint 200 with i-Drive Power)
Input Voltage, Frequency (Sprint 200 with i-Drive Power)
Maximum Power Input (Sprint 200 with i-Drive Power)
Ingress Protection according to EN 60529
(Sprint 200 with i-Drive Power)
Batteries of the i-Drive Power system
Fuses in the i-Drive Power system
Version 100V AC
Version 110V AC
Version 120V AC
Version 127V AC
Version 230V AC
Electric Protection Class (Sprint 200 with i-Drive Power)
24
Parameter
Parameter
216 cm x 89 cm
40 cm
137 cm
20,6 cm
203 cm x 76 cm
20 cm
16 cm
21 cm
10,7 cm
53 cm — 86 cm
90°
40°
25°
+17°/-17°
115°
143 kg / 315 lb
154 kg / 340 lb
320 kg / 705 lb
280 kg / 617 lb
486 kg / 1071 lb
497 kg / 1096 lb
7,5 cm / 3 cm
71 dBA
Value
100V AC, 50/60 Hz
110V AC, 50/60 Hz
120V AC, 50/60 Hz
127V AC, 50/60 Hz
230V AC, 50/60 Hz
400 VA
IPX4
3 x 12V 9Ah VRLA
2 x T3,15A L 250V
2 x T3,15A L 250V
2 x T3,15A L 250V
2 x T3,15A L 250V
2 x T1,6A L 250V
Class I
Value
