9.2 Head Board and Foot Board

WARNING!
Risk of injury when inserting the head board and foot board!
► To insert head board and foot board into corner posts, hold them by the corner handles on top with both hands.
► Install head board and foot board before the first use.
WARNING!
Risk of injury due to incorrectly installed head board and foot board!
► Ensure head board and foot board are correctly inserted, especially when moving the bed.
► Ensure head board locks and foot board locks are locked, especially when moving the bed.
WARNING!
Risk of injury when removing the head board and foot board!
► Before removing head board and foot board, ensure siderails are folded down and there are no accessories atta-
ched to the head board and foot board.
► If a patient is lying in a bed with the head board and/or foot board removed, supervise the bed at all times.
WARNING!
Material damage due to excess load!
► Ensure nobody sits on the head board or foot board.
NOTE: The head board and foot board may be delivered in several decor colour variants.

9.2.1 Aluminium head board and foot board

Fig. Locking the head board or foot board (aluminium head board and foot board)
1. Locked
2. Unlocked
Manipulation with head board and foot board
Insert the head board or foot board as follows:
Unlock safety levers on corner posts (red arrow on the picture marks direction).
►
► Slide head board or foot board into slots on corner posts with coloured panel on the outside.
► Lock safety levers on corner posts.
Remove the head board or foot board as follows:
► Unlock safety levers on corner posts.
► Pull head board or foot board upward.
