Attachment A Page 1 Of 6; Preventative Maintenance Schedule Checklist - CUSTOM ULTRASONICS 83 Plus System 2 Service Manual

Person Performing PM Print Name:
System Type: 83 Plus 2 (Bay 1)
External Inspection of the System 83 Plus
Bay 1 Bay 2 External Inspection
Inspect chassis for
cleanliness
Check all Warnings /
Indicator labels
Inspect power cords
Inspect the power lid(s)
and foot pedal(s)
Inspect the water fill
and drain hoses
Inspect the detergent
bottle, tubing, and
fittings
Inspect the water filter
housings and gauges
Inspect the keyboard,
computer, and printer
Process Info Log Review
Bay 1 Bay 2 Process Info Review
Process Info Log
Service Screen Component Testing
Component Check
Bay 1 Bay 2
(Check in Service Screen)
Water Solenoid
Ultrasonics
Drain/HLD Return Pump
Initials of person performing PM:
MAN–202

Preventative Maintenance Schedule Checklist

Quarterly Maintenance
83 Plus 9 (Bay 1, Bay 2)
• Checked overall cleanliness of the system and external components.
• Labels are present and legible on outside on the chassis.
• System is properly connected to AC outlet.
• Inspected for wear and damage.
• All lids are properly resting on the seal.
• Checked for cracks or broken lids or hinges.
• Checked hinges for wear and tear.
• Checked foot pedal and cable for wear and damage.
• Hoses are secure. Inspected for cracking and leaks.
• Checked bottle level; replaced as necessary.
• Checked tubing for kinks and damage.
• Checked fittings for leaks.
• Inspected housing for leaks, gauges for damage.
• Inspected keyboard cover for puncture, tears and wear.
• Inspected the keyboard for damage and that it is properly connected to the
computer.
• Inspected the computer for damage to the display and that all connections are
secure.
• Checked the printer is present and connected to the computer.
Navigated to the process information screen.
• Reviewed the error log from the date of the last preventative maintenance
Activated the Water valve.
• Verified the Water valve output indicator illuminates on the left side of the service
screen.
• Verified the Flow input indicator illuminates on the right side of the service screen.
• Heard a click when activated.
Filled the processing chamber with water and activated the Ultrasonics.
• Verified the Ultrasonics output indicator illuminates on the left side of the service
screen.
• Verified the Ultrasonics input indicator illuminates on the right side of the service
screen
Activated the Drain pump.
• Verified the Drain pump output indicator illuminates on the left side of the service
screen.
• Heard the pump when activated.
Revision 03082022
System 83 Plus™ Washer/Disinfector
Service Manual
Device S/N:
Checked / Inspected
Checked
Activated and Tested
Date:

Attachment A Page 1 of 6
