Detergents

Tergal 800 Detergent is validated for use in the System 83 Plus™. The automatic injection of Tergal 800
®
is pre-set by Custom Ultrasonics.
CAUTION:
Tergal 800
®

High Level Disinfectant (HLD)

Ortho-Phthalaldehyde Solution high-level disinfectant (OPA) is validated for use in the System 83 Plus™ with a
nominal active ingredient composition of 0.55%, having a Minimum Recommended Concentration (MRC) of 0.3%,
minimum contact condition of 12 minutes at 20°C, and a re-use period not to exceed 14 days. The immersion time
and temperature for the HLD is pre-set by Custom Ultrasonics.
WARNING: Use of HLDs other than OPA have not been validated in the System 83 Plus™ and are not
recommended for use by Custom Ultrasonics.

Electrical Safety

The System 83 Plus™ complies with IEC 60601-1 Medical Electrical Equipment – Part 1: General Requirements for
Basic Safety and Essential Performance and IEC 60601-1-2 General Requirements for Safety - Collateral Standard:
Electromagnetic Compatibility.

Electrical Rating

System Electrical: 110 VAC, 10 AMP, 60 Hz (per bay).

Physical Description of System 83 Plus™

• Dimensions
System 83 Plus™ 2: 62" (H) x 34" (W) x 34" (D)
System 83 Plus™ 9: 62" (H) x 68" (W) x 34" (D)
• Weight
System 83 Plus™ 2: 350 lbs. (Approximate Dry Weight)
System 83 Plus™ 9: 700 lbs. (Approximate Dry Weight)
• Heat Load
System 83 Plus™ 2: ~3583 BTU / Hr.
System 83 Plus™ 9: ~6142 BTU / Hr.
MAN–202
is a detergent; it is NOT a High-Level Disinfectant.
Revision 03082022
System 83 Plus™ Washer/Disinfector
Service Manual
Detergent
®
Page 12 of 54
