CUSTOM ULTRASONICS 83 Plus System 2 Service Manual page 52

System Type: 83 Plus 2 (Bay 1)
Internal Filters and Backpack Filter
Bay 1 Bay 2
(Only Use OEM Parts)
100 Micron Capsule Filter
(P/N 11087)
HEPA Filter Element
(P/N 13075)
Charcoal Filter
(P/N 21017)
High Level Disinfection for the Alcohol Line and Detergent Line
Bay 1 Bay 2 Disinfection
Alcohol Line Disinfection
Detergent Line Disinfection
Pumps and Flow Probe
Open and Inspect
Bay 1 Bay 2
(Only Use OEM Parts)
Drain/HLD Return Pump
Impeller (P/N 11009) and
Pump Shaft (P/N 11135)
HLD Feed Pump
Impeller (P/N 11009) and
Pump Shaft (P/N 11135)
Flow Probe
Processing Chamber Bulkheads and Air Pump Intake Filter
Replace
Bay 1 Bay 2
(Only Use OEM Parts)
Female Adapter Ports
(P/N 18022)
Air Pump Intake Filter
(P/N 20010)
Ultrasonic Generator
Replace
Bay 1 Bay 2
(Only Use OEM Parts)
Ultrasonic Generator
Board
(P/N 12008)
Ultrasonic Feedback
Signal Board
(P/N 12073)
Initials of person performing PM:
MAN–202
83 Plus 9 (Bay 1, Bay 2)
Filter
• Replaced the 100 Micron Capsule Filter.
• Replaced the HEPA Filter Element.
• Replaced the Charcoal filter, as applicable.
• Performed and completed alcohol line disinfection.
• Performed and completed detergent line disinfection.
Biannual Preventative Maintenance
• Opened and inspected, replaced as necessary.
• Opened and inspected, replaced as necessary.
• Removed, inspected, cleaned as necessary, and then re-installed.
Annual Preventative Maintenance
• Replaced female adapter ports.
• Replaced air pump intake filter.
Five Year Replacement
• Replaced the ultrasonic generator board.
• Replaced the ultrasonic signal circuit board.
Revision 03082022
System 83 Plus™ Washer/Disinfector
Service Manual
Device S/N:
Replaced
Disinfected
Checked / Inspected
Replaced
Replaced
Date:
Attachment A Page 5 of 6
