Reports Screen

Reports allows lookup of Purge Log, Backup Log, Shutdown Log and Process Information. Enter the Process
Information screen to review system errors.
CAUTION:
The System 83 Plus™ must not be connected to the facilities network.
NOTE: The facility should have some form of back up, e.g. paper printout or USB drive.
NOTE: Only use freshly formatted USB drives that are formatted on a known safe and secure facility computer
to back up the database and to export reports.

Process Info Screen

Process Information will be the area that allows lookup of errors and cycles performed on based on date range. To
look up the error from the main menu screen:
1. Press (R) to enter Reports. Press (I) to enter Process Info. See the illustration below
2. To delete the existing date in the From box use the (BACKSPACE) key.
3. Type in the new From date in the From box and press (TAB).
4. To delete the existing date in the To box use the (BACKSPACE) key.
5. Type the new To date in the To box and press (TAB), arrow down to highlight the bay to apply the search to,
press (TAB), arrow down and highlight desired type of search then press (TAB).
6. Optionally you can also filter the search by instrument or physician, highlight appropriate search box and arrow
down to select the instrument or physician.
7. Once all search parameters are entered press (F1) Get Data to execute the search.
8. Press (F5) to print all the information. Press (F10) to access the data grid and use the arrow keys to highlight
and press (F7) to print the selected report. Press (F2) to restart another search. Press (F8) to close.
MAN–202
System 83 Plus™ Washer/Disinfector
Illustration: Process Info Screen
