1 Power supply unit 0 status
LEDs OK: green Power
Supply Fail: amber AC OK:
green
4 Power supply unit 1 AC inlet 5 System status LEDs Power:
7 Cluster card slot
10 PCIe slots 5-9
13 DB-15 video connector
Overview of the Sun ZFS Storage 7320 Controller
This section provides an overview of the Sun ZFS Storage 7320 controller. For
installation instructions, refer to
service instructions, refer to
Appliance Customer Service Manual, Release OS8.8.x.
Sun ZFS Storage 7320 Electrical Specifications
The following list shows the electrical specifications for the Sun ZFS Storage 7320
controller.
Note:
The power dissipation numbers listed are the maximum rated power
numbers for the power supply. The numbers are not a rating of the actual
power consumption of the appliance.
Connectors
•
Two C13 connectors, which work on 110-220v outlets
Input
•
Nominal frequencies: 50/60Hz
•
Nominal voltage range: 100-120/200-240 VAC
•
Maximum current AC RMS: 9.0 amps Max
•
AC operating range: 90-264 VAC
Output
•
3.3 VDC STBY: 3.6A
•
+12 VDC: 62.3A
Power dissipation
Overview of the Sun ZFS Storage 7320 Controller
2 Power supply unit 0 AC inlet 3 Power supply unit 1 status
green Attention: amber
Locate: white
8 Network (NET) 10/100/1000
ports: NET 0-NET 3
11 Network management
(NET MGT) 10/100 BASE-T
Ethernet port
Installing a Sun ZFS Storage 7x20
Servicing the 7x20 Controller
Chapter 2
LEDs OK: green Power
Supply Fail: amber AC OK:
green
6 PCIe slots 0-4
9 USB 2.0 ports
12 Serial management (SER
MGT) port
Controller. For
in Oracle ZFS Storage
2-54
