1 Locate button and indicator
4 Disk ready to be removed
indicator
7 Over temperature warning
indicator
Sun Disk Shelf Rear Panel
1 Power supply modules with built-in fans. Power
supply 0 is on the left and power supply 1 is on the
right.
Sun Disk Shelf SIM Board Indicators
2 System fault indicator
5 Disk fault indicator
8 SIM board fault indicator
2 Removable SAS Interface Module (SIM) Boards.
SIM 0 is on the left, and SIM 1 is on the right.
Chapter 2
Overview of Disk Shelves
3 System power indicator
6 Disk activity indicator
9 Power supply fault indicator
2-25
