Callout
Description
1
Shelf 8 (RU 35-38)
2
Shelf 7 (RU 31-34)
3
Shelf 6 (RU 27-30)
4
Shelf 5 (RU 23-26)
5
Controller 1 (RU 20-22)
Connecting Disk Shelf Cables
Callout
Description
6
Controller 2 (RU 17-19)
7
Shelf 4 (RU 13-16)
8
Shelf 3 (RU 9-12)
9
Shelf 2 (RU 5-8)
10
Shelf 1 (RU 1-4)
