Oracle ZFS Storage ZS5-4 Acoustic Noise Emissions

In compliance with the requirements defined in ISO 9296, the workplace-dependent noise
level of this product is less than 75 dBA (bystander position, max. ambient).

Oracle ZFS Storage ZS5-4 Configuration Options

Oracle ZFS Storage ZS5-4 incorporates one or two controllers and one to forty-eight disk
shelves. Each controller has eleven PCle Gen3 slots. Each controller includes six 2.5'' disk
slots that accommodate two system disks. Read cache devices are installed in disk shelves;
therefore, the remaining four disk slots have permanent filler panels. The following table
describes the configuration options.
CPU
4x18-core, 2.6
GHz
The most recent component specification is located at
index.html

Oracle ZFS Storage ZS5-4 Front Panel Components

The Oracle ZFS Storage ZS5-4 controller drive slots and front panel components are shown
in the following figure.
1 LEDs (left to right)
• Locator
• Service action required
• Power/OK
Memory
1536 GB
.
2 Power button
Overview of the Oracle ZFS Storage ZS5-4 Controller
System Disks PCIe Slots
2x2.5'' SAS-3 Four dedicated;
seven available
https://www.oracle.com/storage/nas/
3 Alert indicators (left to right)
•
•
•
•
Chapter 2
HBA
4-port (4x4) SAS-3
12 Gb/s external
4-port (4x4) SAS-2
6 Gb/s external
Service Processor (SP) OK/
Fault
Fan/ CPU/ Memory service
action required
Power Supply (PS) service
action required
Over-temperature warning
