1 Locate indicator
4 Power supply fault indicator
7 Drive service required indicator 8 Power/Activity indicator
Oracle Storage Drive Enclosure DE3-24C Rear Panel
1 Power supply filler panel, slot 4 2 I/O Module 1
4 Power supply with fan module
2
7 I/O Module 0
Note:
It is especially important that power supplies and their filler panels are in the correct
slots.
Oracle Storage Drive Enclosure DE3 I/O Module Indicators
2 Service required indicator
5 SAS I/O Module fault indicator
5 Power supply filler panel, slot 2 6 I/O Module filler panel
8 Power supply with fan module
1
Chapter 2
Overview of Disk Shelves
3 OK indicator
6 Ready-to-remove indicator
3 I/O Module filler panel
2-19
