1 AC power indicator
4 Power supply fault indicator
7 Port fault indicator
10 SIM locator indicator
Sun Disk Shelf Power Supply and Fan Module Indicators
1 Cooling fan status indicator
4 Power supply status
indicator
2 DC power indicator
5 Universal power connector
8 Port OK indicator
2 AC power status indicator
5 Power on/off switch
Chapter 2
Overview of Disk Shelves
3 Fan fault indicator
6 Power switch
9 SIM board OK indicator
(green)/SIM board fault
indicator (amber)
3 DC power status indicator
6 Power cord tie wrap
2-26
