Caution:
Do not connect the power cables until instructed to do so in
Appliance.
The cabling configuration for your appliance depends on the number and type of
controllers and disk shelves, as well as the number of host bus adapters (HBAs) in
your system. Disk shelves attach to other disk shelves with daisy-chained serial
attached SCSI (SAS) cables. Controllers attach to each disk shelf chain with a longer
SAS cable connected via HBAs located in specified PCIe slots of the controllers.
Clustered controllers are attached via three Ethernet cables that provide redundant
communication channels: two serial links and an Ethernet link. The cabling
methodology designed for the appliance includes bottom-to-top cabling for easier
growth with optimum safety, strategic slot placement for optimum load distribution and
performance, and interface redundancy for clustered controllers, ensuring no single
point of failure.
Locate the appropriate cabling configuration for your system in
1.
with Cabling in Oracle ZFS Storage Appliance Cabling Guide, Release OS8.8.x.
• Cabling Oracle Storage Drive Enclosure DE3-24 Disk Shelves to 4X4 Port
SAS-3 HBAs in Oracle ZFS Storage Appliance Cabling Guide, Release
OS8.8.x
• Cabling Oracle Storage Drive Enclosure DE2-24 Disk Shelves to 4X4 Port
SAS-2 HBAs in Oracle ZFS Storage Appliance Cabling Guide, Release
OS8.8.x
• Cabling Oracle Storage Drive Enclosure DE2-24 Disk Shelves to 2X4 Port
SAS-2 HBAs in Oracle ZFS Storage Appliance Cabling Guide, Release
OS8.8.x
• Cabling Sun Disk Shelves
Release OS8.8.x
• Cabling Mixed Oracle Storage Drive Enclosure DE3-24 and DE2-24 Disk
Shelves in Oracle ZFS Storage Appliance Cabling Guide, Release OS8.8.x
• Cabling Mixed Oracle Storage Drive Enclosure DE2-24 and Sun Disk Shelves
in Oracle ZFS Storage Appliance Cabling Guide, Release OS8.8.x
Connect cables between disk shelves and between storage controller(s) and disk
2.
shelves.
If clustered controllers, be sure to connect the cluster cables as described in
Connecting Cluster Cables.
Example 11-1 Disk Shelf Cabling Example
The following illustration shows the cable connections for two clustered Oracle ZFS
Storage ZS4-4 controllers and eight Oracle Storage Drive Enclosure DE2-24C disk
shelves. The controllers, as recommended, are located in the middle of the cabinet.
For cabling diagrams of specific configurations, refer to
Oracle ZFS Storage Appliance Cabling Guide, Release OS8.8.x.
in Oracle ZFS Storage Appliance Cabling Guide,
Getting Started with Cabling
Chapter 11
Connecting Disk Shelf Cables
