Alinx ZYNQ UltraScale+ AXU2CG-E User Manual page 45

J45 Pin Signal Name
1
3 B45_L9_N
5 B45_L5_N
7 B45_L12_N
9 B45_L11_N
11 B45_L6_N
13 B46_L6_N
15 B46_L3_N
17 B46_L2_N
19 B46_L4_N
21 B46_L12_N
23 B45_L4_N
25 B46_L11_N
27 B46_L10_N
29 B46_L7_N
31 B46_L9_N
33 B46_L5_N
35 B46_L1_N
37
39
J46 Expansion Header Pin Assignment
J46 Pin Signal Name
1
3 B43_L2_N
5 B44_L8_N
7 B44_L9_N
9 B44_L11_N
11 B43_L10_N
13 B43_L12_N
15 B44_L3_N
17 B44_L12_N
19 B44_L1_N
21 B44_L5_N
45 / 56
ZYNQ Ultrascale + FPGA Board AXU2CG-E User Manual
Pin Number
GND -
B10
F10
C12
A11
F11
E13
A13
A14
C13
L13
H12
J14
H13
F13
G14
D14
A15
GND -
+3.3V -
Pin Number
GND -
AG11
AB14
W13
W11
Y10
AB9
AH13
AA12
AE14
AD14
J45 Pin Signal Name
2 +5V
4 B45_L9_P
6 B45_L5_P
8 B45_L12_P
10 B45_L11_P
12 B45_L6_P
14 B46_L6_P
16 B46_L3_P
18 B46_L2_P
20 B46_L4_P
22 B46_L12_P
24 B45_L4_P
26 B46_L11_P
28 B46_L10_P
30 B46_L7_P
32 B46_L9_P
34 B46_L5_P
36 B46_L1_P
38 GND
40 +3.3V
J46 Pin Signal Name
2 +5V
4 B43_L2_P
6 B44_L8_P
8 B44_L9_P
10 B44_L11_P
12 B43_L10_P
14 B43_L12_P
16 B44_L3_P
18 B44_L12_P
20 B44_L1_P
22 B44_L5_P
Pin Number
-
C11
G11
D12
A12
F12
E14
B13
B14
C14
L14
J12
K14
H14
G13
G15
D15
B15
-
-
Pin Number
-
AF11
AB15
W14
W12
W10
AB10
AG13
Y12
AE15
AD15
