Intermec EasyCoder 201 II – Technical Manual
PAPER DIMENSIONS, cont'd.

Self-adhesive Labels

a
b
c
SELF-ADHESIVE
LABELS
e
PAPER FEED
DIRECTION
1
/. The last third of a label with maxi-
mum length cannot be used for print-
ing! Also see "Max. printable length".
NORMAL ROLL PRINTERS:
a Web width (incl. backing paper):
Maximum .................................................. :
Minimum .................................................. :
b Label width (excl. backing paper):
Maximum .................................................. :
Minimum .................................................. :
c Label length:
Max. label length (6 dots/mm)
Max. label length (8 dots/mm)
Min. label length (all) ................................ :
Max. printable length (6 dots/mm) ............. :
'
d Label gap:
Maximum .................................................. :
Recommended ........................................... :
d
Minimum .................................................. :
The label stop sensor must be able to detect the extreme edges of the labels.
Therefore the corner radii must not exceed 2.0 mm (0.08").
e Backing paper:
The backing paper must not extend more than 1.6 mm (0.06") outside the
paper and should protrude equally on both sides.
Minimum transparency: 40% (DIN 53147)
"BIG ROLL" PRINTERS (7" internal roll):
e
a Web width (incl. backing paper):
Maximum .................................................. :
Minimum .................................................. :
b Label width (excl. backing paper):
Maximum .................................................. :
Minimum .................................................. :
c Label length:
Max. label length (6 dots/mm)
Max. label length (8 dots/mm)
Min. label length (all) ................................ :
Max. printable length (6 dots/mm) ............. :
Max. printable length (8 dots/mm) ............. :
d Label gap:
Maximum .................................................. :
Recommended ........................................... :
Minimum .................................................. :
The label stop sensor must be able to detect the extreme edges of the labels.
Therefore the corner radii must not exceed 2.0 mm (0.08").
e Backing paper:
The backing paper must not extend more than 1.6 mm (0.06") outside the
paper and should protrude equally on both sides.
Minimum transparency: 40% (DIN 53147)
89.0 mm
40.0 mm
87.4 mm
38.4 mm
1
.................. : 2475 mm
1
.................. : 1875 mm
15.0 mm
1650 mm
10.0 mm
1.6 mm
1.2 mm
80.2 mm
40.0 mm
78.6 mm
38.4 mm
1
.................. : 2475 mm
1
.................. : 1875 mm
15.0 mm
1650 mm
1250 mm
10.0 mm
1.6 mm
1.2 mm
(3.50")
(1.58")
(3.44")
(1.51")
(97.4")
(73.8")
(0.59")
(65.0")
(0.39")
(0.06")
(0.05")
(3.16")
(1.58")
(3.10")
(1.51")
(97.4")
(73.8")
(0.59")
(65.0")
(49.2")
(0.39")
(0.06")
(0.05")
53
