Chapter 3 Operation

Ribbon Load

1
1
Open the side and front covers.
18
You do not need any thermal transfer ribbon when printing on
heat-sensitive materials. When you use the thermal transfer printing
method, it is important to match the type of transfer ribbon with the
receiving face material you are using.
Thermal transfer 'ink' does not smear at normal room temperature.
In case of ribbon wrinkling problems, see Chapter 5, "Troubleshoot-
ing" for instructions.
Intermec thermal transfer ribbons are engineered specifi cally for
the EasyCoder E4 printhead.
2
Important!
2
2
Raise the printhead and remove any used
ribbon and the empty core. Keep the empty
core for use with next ribbon load.
Intermec EasyCoder E4 – Installation & Operation Ed. 2
