Service

This subsection provides the instructions for performing
maintenance and making checks and adjustments. Stan-

Maintenance Points

1

Maintenance Schedule

The Maintenance Schedule is a program that includes
periodic inspection and lubrication. Use the operating
INTERVAL
50 hours or weekly
500 hours or ever y 3
months
1000 hours or every 6
months
* NOTE: Clean the oil strainer screen and change the oil fi lter after the fi rst 250 hours on new and rebuilt winches.
† Amount of oil may vary slightly with tractor.
4
1. Access Cover for Control Valve
2. Plug to Check Oil Level
3. Plug to Drain Oil
Figure 2-13 W8L Maintenance Points
PROCEDURE OR QUANTITY
Check oil level at plug (item 2). Add oil as necessary
through fi ll plug (item 5). Do not operate tractor when
checking the oil level.
Check winch control lever (cable controls). See Figs.
2-15 & 2-16.
Clean the breather (item 6).
Lubricate the rollers on the fairlead assembly, if the
winch is so equipped.
Clean the oil suction screen and magnets.*
Clean the breather.
Replace the fi lter.*
Change the hydraulic oil. Drain oil from plug (item 3).
Clean the oil strainer. Through fi ll plug (item 5), add 20
†
gallons (75 liters) . Check the oil level at item 2.
Figure 2-14 Maintenance Schedule
dard shop tools are used in doing the work described in
this section.
3
4. Cover for Filter
5. Fill Plug
6. Breather
time on the hour meter of the tractor to determine the
maintenance time for the winch.
See Figure 1-12 – Recommended Oil List.
Use SAE 30 oil on the linkage if needed. Check
that the control cable and control housing are
fastened correctly. Tighten U-bolts if required.
Remove debris around breather.
Use multi-purpose grease with 2-4% molyb-
denum disulfi de.
Use a new gasket between the cover and the
suction tube.
Remove debris around breather.
See the Parts Manual for fi lter element and
cover gasket. When replacing, be sure to
lubricate fi lter seal ring between element and
fi lter head.
See Figure 1-12 – Recommended Oil List.
Section 2
5
6
2
SPECIFICATION
2 - 11
