SuperServer E403-9D-16C-IP User's Manual

1.1 Overview

This chapter provides a brief outline of the functions and features of the AC-powered platform
SuperServer E403-9D-16C-IP. Applications for this server includes 5G Radio Access Network
(RAN), Multi-Access Edge Computing (MEC), Edge AI Inferencing, Vehicle to Everything
(C-V2X/V2X) and Virtualized Functions and Services. The system is also suitable for Network
Telecommunication Facilities. This system is based on the X11SDW-16C-TP13F motherboard
and the CSE-RACK2U-IP65 IP65 Enclosure.
In addition to the motherboard and chassis, several important parts that are included with
the system are listed below.
Description
Air shroud
System fans
Power supply module
Note: the following safety models associated with the E403-9D-16C-IP have been certified
as compliant with UL or CSA: RACK2U-E403-IP.
Several terms that are used in the manual when describing the E403-9D-16C-IP are defined
below:
System: Includes the outdoor enclosure and the server.
Enclosure: The housing that contains the server and provides protection from the environment
Server: The computing unit that includes the chassis, motherboard, storage, add-on-module,
etc.
Chassis: The enclosure for the server.
Chapter 1
Introduction
Main Parts List
Part Number
MCP-310-50502-0B
FAN-0201L4
PWS-601-1H
8
Quantity
1
3
1
