SuperServer E403-9D-16C-IP User's Manual

2.2 Preparing for Setup

Pole Mounting Requirements

Manpower: Three people
Tools: Adjustable wrench with diameter 1.3 (32mm)
Phillips #1 and #2 screwdrivers
One breaker that can support 1200W power, with leakage and surge protection
and GFCI. (DIN rail mount)
Measuring tape
Surge protection devices (SPD), DIN rail mount
Shielded dual-conductor cable (16 AWG)
Marking pen
Item Description
1 Spacer
2 Holding bar
3 Thread rod
4 M3 screw
5 M10 nut
6 Washer
AC-out cable
Thread rod
Accessory Package Items
Quantity Item Description
2 7 Spring washer
2 8 M8 nut
4 9 Cable gland
12 10 Hoist ring
4 11 Door key
4 12 AC out cable
L
N
PE
Hoist ring
Figure 2-1. Accessories
20
Quantity
4
8
1
2
2
2
Holding bar
Spacer
Cable gland
