LAN Port Activity LED
JLANLED1 is the activity LED for LAN1, JLANLED2 is the activity LED for LAN2 - LAN5, and
JLANLED3 is the activity LED for LAN6 - LAN9.
JTGLED1, JTGLED2
JTGLED1 is the activity LED for LAN10 - LAN11, and JTGLED2 is the activity LED for LAN12
- LAN13.
JLANLED1
LAN Activity LED
Pin Definitions
Pin# Definition
1 P3V3 Dual
2 GLAN1_ACT_N
JLANLED2
LAN Activity LED
Pin Definitions
Pin# Definition Pin# Definition
1 P3V3 Dual 2 LINK0_ACT_N
3 P3V3 Dual 4 LINK1_ACT_N
5 P3V3 Dual 6 LINK2_ACT_N
7 P3V3 Dual 8 LINK3_ACT_N
JLANLED3
LAN Activity LED
Pin Definitions
Pin# Definition Pin# Definition
1 P3V3 Dual 2 LINK4_ACT_N
3 P3V3 Dual 4 LINK5_ACT_N
5 P3V3 Dual 6 LINK6_ACT_N
7 P3V3 Dual 8 LINK7_ACT_N
JTGLED1
LAN Activity LED
Pin Definitions
Pin# Definition
1 P3V3 Dual
2 10G_P0_ACT_N
3 P3V3 Dual
4 10G_P1_ACT_N
JTGLED2
LAN Activity LED
Pin Definitions
Pin# Definition
1 P3V3 Dual
2 10G_P2_ACT_N
3 P3V3 Dual
4 10G_P3_ACT_N
