VGA Header
Connect a 16-pin VGA extension cable to JVGA1 for a VGA connecton.
Intel RAID Key Header
The JRK1 header allows the user to enable RAID functions. Refer to the table below for pin
definitions.
Disk On Module Power Connector
The Disk On Module (DOM) power connector at JSD1 provides 5V power to a solid state
DOM storage device connected to one of the SATA ports. Refer to the table below for pin
definitions.
VGA Header
Pin Definitions
Pin#
Definition
Pin#
Definition
1
VGA_RED
2
VGA_GRE
3
VGA_BLE
4
N/C
5
GND
6
VGA_DET (GND)
7
GND
8
GND
9
5V
10
GND
11
N/C
12
DDCSDA
13
HSYNC
14
VSYNC
15
DDCSCL
16
N/C
Intel RAID Key
Pin Definitions
Pins
Definition
1
GND
2
PU 3.3V Stdby
3
GND
4
PCH RAID KEY
DOM Power
Pin Definitions
Pin#
Definition
1
5V
2
Ground
3
Ground
