Power Button
The Power Button connection is located on pins 1 and 2 of JF1. Momentarily contacting both
pins will power on/off the system. This button can also be configured to function as a sus-
pend button (with a setting in the BIOS - see Chapter 6). To turn off the power in the suspend
mode, press the button for at least seconds seconds. Refer to the table below for pin defini-
Reset Button
The Reset Button connection is located on pins 3 and 4 of JF1. Attach it to a hardware reset
switch on the computer case to reset the system. Refer to the table below for pin definitions.
Power Fail LED
The Power Fail LED connection is located on pins 5 and 6 of JF1. Refer to the table below
for pin definitions.
Chapter 4: Motherboard Connections
tions.
Power Button
Pin Definitions (JF1)
Pins
Definition
1
Signal
2
Ground
Reset Button
Pin Definitions (JF1)
Pins
Definition
3
Reset
4
Ground
Power Fail LED
Pin Definitions (JF1)
Pin#
Definition
5
+3.3V
6
PWR LED
57
