J3 Connector Pinout - Intel NetStructure ZT 5515 Product Specification

Table 25. J3 Connector Pinout
A.3.2.4
®
Intel NetStructure
Downloaded from Elcodis.com electronic components distributor
Pin# A
19 NC NC
18 MDIOAX0+ MDIOAX0-
17 MDIOAX1+ MDIOAX1-
16 MDIOBX0+ MDIOBX0-
15 MDIOBX1+ MDIOBX1-
14 VCC3 VCC3
13 PMC IO [1] PMC IO [2]
12 PMC IO [6] PMC IO [7]
11 PMC IO [11] PMC IO [12]
10 PMC IO [16] PMC IO [17]
9 PMC IO [21] PMC IO [22]
8 PMC IO [26] PMC IO [27]
7 PMC IO [31] PMC IO [32]
6 PMC IO [36] PMC IO [37]
5 PMC IO [41] PMC IO [42]
4 PMC IO [46] PMC IO [47]
3 PMC IO [51] PMC IO [52]
2 PMC IO [56] PMC IO [57]
1 PMC IO [61] PMC IO [62]
Pin# A
J5 (Rear Panel I/O CompactPCI Connector)
J5 is a 110-pin 2 mm x 2 mm female connector (AMP 352152-1) providing rear-panel user I/O.
See the "J5 Rear Panel I/O Connector Pinout" table below for pin definitions and
page 64 for pin placement.
TM
ZT 5515 Compute Processor Board Technical Product Specification
B C
NC NC
GND MDIOAX2+
GND MDIOAX3+
GND MDIOBX2+
GND MDIOBX3+
VCC3 VCC
PMC IO [3] PMC IO [4]
PMC IO [8] PMC IO [9]
PMC IO [13] PMC IO [14]
PMC IO [18] PMC IO [19]
PMC IO [23] PMC IO [24]
PMC IO [28] PMC IO [29]
PMC IO [33] PMC IO [34]
PMC IO [38] PMC IO [39]
PMC IO [43] PMC IO [44]
PMC IO [48] PMC IO [49]
PMC IO [53] PMC IO [54]
PMC IO [58] PMC IO [59]
PMC IO [63] PMC IO [64]
B C
Specifications
D E
NC
MDIOAX2-
MDIOAX3-
MDIOBX2-
MDIOBX3-
VCC
PMC IO [5]
PMC IO [10]
PMC IO [15]
PMC IO [20]
PMC IO [25]
PMC IO [30]
PMC IO [35]
PMC IO [40]
PMC IO [45]
PMC IO [50]
PMC IO [55]
PMC IO [60]
VIO
D E
