J25 Vga Connector Pinout; J20 Universal Serial Bus 0 Connector Pinout; J30 Com1 Serial Port Pinout - Intel NetStructure ZT 5515 Product Specification

Specifications
Table 28. J25 VGA Connector Pinout
A.3.2.7
Table 29. J20 Universal Serial Bus 0 Connector Pinout
A.3.2.8
Note: COM1 signals are available to the front- and rear-panel (at J5) simultaneously. Utilizing COM1 at
Table 30. J30 COM1 Serial Port Pinout
70
Downloaded from Elcodis.com electronic components distributor
Pin# Signal
1 RED
2 GREEN
3 BLUE
4 NC
5 DGND
J20 (Universal Serial Bus 0 connector)
J20 (Port0) is a Universal Serial Bus (USB) Interface connector (AMP 440260-1). See the "J20
Universal Serial Bus 0 Connector Pinout" table below for pin definitions.
USB port 0 is only available from the front USB connector, but USB Ports 2 and 3 are routed out J5
for use with a RPIO board.
Pin# Function
1 Vcc (Fused)
2 DATA-
3 DATA+
4 GND
J30 (COM1 Serial Port)
J30 is an RJ-45 connector providing a front-panel COM1 interface. COM1 signals are also directed
out J5 to the backplane. See the "J30 COM1 Serial Port Pinout" table below for pin definitions.
SRI (Serial Ring Indicator) and SCD (Serial Carrier Detect) signals are not included in the front
panel RJ-45 connector.
the front and rear at the same time will cause a signaling conflict.
Pin# Function
1 RTS
2 DTR
3 TXD
4 GND
5 GND
®
TM
Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification
Pin# Signal
6 RGND
7 GGND
8 BGND
9 +5V (fused)
10 SGND
Pin# Function
6 RXD
7 DSR
8 CTS
- SRI
- SCD
Pin# Signal
11 NC
12 DDC DAT
13 HSYNC
14 VSYNC
15 DDC CLK
