Specifications
Table 24. J2 CompactPCI Bus Connector Pinout
A.3.2.3
66
Downloaded from Elcodis.com electronic components distributor
Pin# A
22 GA4 GA3
21 SS_CLK6 SS_GND2
20 SS_CLK5 SS_GND3
19 SS_GND4 SS_GND1
18 BRSVP2A18 BRSVP2B18
17 BRSVP2A17 GND
16 BRSVP2A16 BRSVP2B16
15 J2STAGEEN# GND
14 AD[35] AD[34]
13 AD[38] GND
12 AD[42] AD[41]
11 AD[45] GND
10 AD[49] AD[48]
9 AD[52] GND
8 AD[56] AD[55]
7 AD[59] GND
6 AD[63] AD[62]
5 C/BE[5]# 64EN-
4 V(I/O) J2_BPID#
3 SS_CLK4 GND
2 SS_CLK2 SS_CLK3
1 SS_CLK1 GND
Pin# A
J3 (CompactPCI Connector)
J3 is a 95-pin 2 mm x 2 mm female connector (AMP 352171-1). See the "J3 Connector Pinout"
table below for pin definitions and
®
TM
Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification
B C D
GA2 GA1
RSVC21 RSVD21
RSVC20 GND
SMBDATA SMBCLK
BRSVP2C18 GND
SS_PRST SS_REQ6
SS_DEG- GND
SS_FAL- SS_REQ5
AD[33] GND
V(I/O) AD[37]
AD[40] GND
V(I/O) AD[44]
AD[47] GND
V(I/O) AD[51]
AD[54] GND
V(I/O) AD[58]
AD[61] GND
V(I/O) C/BE[4]#
C/BE[7]# GND
SS_GNT3 SS_REQ4
SYSEN- SS_GNT2
SS_REQ1 SS_GNT1
B C D
Figure 10 on page 64 for pin placement.
