A.2
A.3
A.3.1
Table 21. Board Dimensions and Weight
®
Intel
NetStructure
Downloaded from
Elcodis.com
electronic components distributor
Reliability
MTBF:
23.6 years (excluding on-board hard disk drive)
MTTR:
3 minutes (based on board replacement), plus system startup
Mechanical
This section includes the following mechanical specifications:
•
Dimensions and weight
•
Connector locations, descriptions, and pinouts
Board Dimensions and Weight
The ZT 5515 meets the CompactPCI Specification, PICMG 2.0, Version 2.1 for all mechanical
parameters. In a CompactPCI enclosure with 0.8 inch spacing.
Mechanical dimensions are shown in the "PCB Dimensions" illustration and are outlined below.
Dimension
PCB Dimensions:
233.35 mm x 160 mm x 1.6 mm
Board Dimensions:
6U x 4HP (one slot)
Weight:
509 grams (18 ounces) w/ processor, heatsink, 512 Mbyte memory
TM
ZT 5515 Compute Processor Board Technical Product Specification
Measurement
Specifications
61
