Datasheet Reference
D.4
D.5
D.6
D.7
84
Downloaded from Elcodis.com electronic components distributor
®
Mobile Intel Pentium 4
(FCPGA Package)
For more information about the Intel Mobile Pentium 4 Processor - M in FCPGA Package, see the
Mobile Intel Pentium 4 processor - M in FCPGA datasheet. This document is available online at:
http://developer.intel.com/design/mobile/pentium4p-m/p4p-m.htm
PMC Specification
For more information about PMC modules and the PMC Specification, refer to the sponsoring
organization's Website at:
http://www.vita.com/
SuperI/O
Refer to the National Semiconductor PC87417 SuperI/O Plug and Play Compatible Chip in
Compact 100-Pin VLJ Packaging datasheet for more information on the following ZT 5515
functions:
•
Floppy Disk controller
•
Serial Port controller
•
Mouse and Keyboard controller
•
Parallel Port
The datasheet is available online from the National Semiconductor Website at:
http://www.national.com
Video
For more information about the Silicon Motion* LynxEM+* with 2 MB Integrated Memory, refer
to the Silicon Motion LynxEM+ datasheet. This and related documents are available online at:
http://www.siliconmotion.com/eng/index2.htm
®
TM
Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification
®
Processor - M
