Specifications
Table 34. J8 IDE Connector Pinout
74
Downloaded from Elcodis.com electronic components distributor
Pin# Signal
1 RST-
3 DDP7
5 DDP6
7 DDP5
9 DDP4
11 DDP3
13 DDP2
15 DDP1
17 DDP0
19 GND
21 PDREQ-
23 PDIOW-
25 PDIOR-
27 PDIORDY
29 PDACK-
31 IRQ14
33 DAP1
35 DAP0
37 CS1P-
39 PDASP
41 VCC
43 GND
CSEL1 has 475Ω pulldown to GND.
a.
b. IOCS16- has 10k pullup to VCC3 (+3.3V).
®
TM
Intel NetStructure ZT 5515 Compute Processor Board Technical Product Specification
Pin# Signal
2 GND
4 DDP8
6 DDP9
8 DDP10
10 DDP11
12 DDP12
14 DDP13
16 DDP14
18 DDP15
20 NC
22 GND
24 GND
26 GND
a
28 CSEL1
30 GND
b
32 IOCS16-
34 PDIAG
36 DAP2
38 CS3P-
40 CS3P-
42 VCC
44 NC
