Matrox M9138 Lp Pcie ×16 And M9148 Lp Pcie ×16; Connection Overview - Matrox C Series User Manual

Device connector
DVI
HDMI
* Only active adapters (sold separately) are supported. Passive adapters aren't supported.
Matrox M9138 LP PCIe ×16 and M9148 LP PCIe ×16
WARNING:
DisplayPort connector on your DisplayPort
monitor cable or on your graphics
hardware, carefully remove the DisplayPort
cable by pressing the latch on the top of the
DisplayPort connector while removing the
connector.

Connection overview

Description
If your monitor has a DVI connector, use a DisplayPort to DVI adapter
*
(active ) to connect your monitor cable to the DisplayPort connector
on your Matrox card. Connect the other end of the cable to your
monitor.
If your monitor has an HDMI connector, use a mini DisplayPort to
HDMI adapter (active
on your Matrox card. Connect your monitor to the HDMI connector
on your adapter.
To avoid damaging the
(M9138 shown)
*
) to connect to the mini DisplayPort connector
Mini DisplayPort to
DisplayPort adapter
Monitor connector
(DisplayPort)
Matrox Display Wall – User Guide 85
