For example, this multi-display layout shows a 5 × 3 display wall on a C-Series based controller with
one (1) C900 card and one (1) C680 card. On C900, each output uses three (3) monitors left to right
and each output is placed one over another to create the 3 × 3 section on the left of the display wall.
On C680, each output uses a single monitor to fill in the 2 × 3 section on the right.
Planning the input of Mura MPX Series and Mura IPX Series
capture cards
Mura MPX Series
are numbered according to the following guidelines:
Cards are ordered in groups based on their order on the PCI bus. These groups are:
1
2
3
Inputs are then ordered according to the order of the connectors on the card.
* Except Mura MPX-4/0.
22 Matrox Mura Display Wall – User Guide
*
and Mura IPX Series capture cards have input connectors. These input connectors
Mura MPX-4/4, MPX-4/2, and MPX-SDI.
You can specify the order of the cards in this group through DIP switches.
Mura MPX-V16 and MPX-V8.
Mura IPX Series capture cards.
You can specify the order of the cards in this group through DIP switches.
