Mura MPX-4/4 and MPX-4/2
This section describes how to connect your output devices (monitors) and input devices to your Mura
MPX-4/4, and MPX-4/2 cards.
Connection overview
(KX20 to Quad-DVI or Dual-DVI)
Monitor
connector
(DVI)
Monitor
connector
(HD-15)
Input cables
S-video
Composite
cable
video cable
(RCA)
Monitor
connector
(DVI)
Component
video cable
Matrox Display Wall – User Guide 39
Output cable
(KX20 to
Quad-DVI)
Monitor
connector
(HD-15)
