  • Page 1 ® Matrox Mura MPX™ Series How to use a Matrox GXM™ product as an output device 20170-101-0100 2012.04.20...
  • Page 2: Before You Begin

    Adding a Matrox DualHead2Go Digital Edition or TripleHead2Go Digital Edition product to your Mura MPX Series setup increases the number of available outputs on your Mura MPX Series card. You can connect up to four (4) GXM units to each Mura MPX card, increasing the number of available outputs on each Mura MPX card to 8 (using DualHead2Go Digital Edition) and 12 (using TripleHead2Go Digital Edition).
  • Page 3: Software Supplied

    DVI to HD-15 adapter USB hub To purchase any Matrox cables or adapters not included with your Matrox product, see the Matrox online store (shopmatrox.com). Software supplied Matrox PowerDesk – to use your Matrox product. Matrox PowerDesk software supports Windows® 7 64-bit and Windows® Server® 2008 R2. Matrox makes new software available on the Matrox Technical Support Web site (www.matrox.com/graphics/en/support/drivers).
  • Page 4: Connecting Your Gxm

    This section explains how to connect your GXM product to your Mura MPX Series card. Before you begin Make sure your Matrox Mura MPX Series cards are already installed in your system and your KX20 to quad-DVI or KX20 to dual-DVI cable (included with your Mura card) is already connected to your Mura MPX card.
  • Page 5 KX20 to quad-DVI or KX20 to (HD-15) dual-DVI cable provided with your Mura MPX Series product. Note: Monitors must be connected directly to your GXM products, not your Mura cards. Matrox Mura MPX Series – Using GXM as output...
  • Page 6 Mura card, and outputs , and are the TripleHead2Go units connected to the outputs of the second Mura card. Your GXM product is now connected. Restart your computer and install your software. Matrox Mura MPX Series – Using GXM as output...
  • Page 7: Setting Up Your Software

    External graphics hardware sure all the GXM products connected to your Mura cards are listed. Note: If any GXM products are missing from the list, verify that your USB cables are properly connected. Matrox Mura MPX Series – Using GXM as output...
  • Page 8 For more information, see Matrox PowerDesk help. Using unlisted display modes For display modes currently unavailable to your Matrox products, Matrox provides increased resolution support by enabling you to select display modes not provided by default in your monitor’s EDID. This means you can access a variety of wide-screen resolutions, video timings, and refresh rates.
  • Page 9: Display Modes

    1 These display resolutions are achieved with one GXM unit connected to one Mura output. For example, connecting four TripleHead2Go Digital Edition units to a single Mura card results in a display resolution of 4800×3600 (3×4 1600×900). Matrox Mura MPX Series – Using GXM as output...
  • Page 10 Contact us The Matrox Web site has product literature, press releases, technical material, a sales office list, trade show information, and other relevant material. Visit us at www.matrox.com/graphics. If you have any questions or comments about our products or solutions, contact us at www.matrox.com/graphics/contact.
  • Page 11 Windows is a registered trademark of Microsoft Corporation in the United States and other countries. Copyright © 2012 Matrox is a registered trademark of Matrox Electronic Systems Ltd. All rights reserved. Matrox Mura MPX Series – Using GXM as output 11...
  • Page 12 Matrox Graphics Inc. 1055 Saint Regis Boulevard Web site: www.matrox.com/graphics Dorval, Quebec, Canada H9P 2T4 Technical support: North America: 1-800-361-1408 www.matrox.com/graphics/support International: (514) 822-6000 To locate the sales office nearest you, visit Email: graphics@matrox.com www.matrox.com/graphics/contact...
