Mura IPX Series 4K DisplayPort Capture and IP Encode/Decode cards

Operating systems supported
Card type
Form factor
Memory
Connectors
Outputs supported
Inputs supported
Maximum DisplayPort input
resolutions
IP stream support
Video CODEC engine
Audio stream support
†‡
H.264 decode
*†‡
H.264 encode
Maximum card dimensions
Regulatory compliance
* Supported only with C-Series.
† Standard resolutions listed above. Support for custom resolutions available. For specific requirements, contact your Matrox
representative.
‡ In YUV 4:2:0, 12 bits per pixel (8 bits per component).
MURAIPXI-E2MF • MURAIPXI-E2MHF
®
Windows 10 64-bit, Windows
®
2016, Windows 7 64-bit, Windows
®
Windows Embedded Standard 7 64-bit, Windows
Embedded Enterprise 7 64-bit, Linux
(×16 mechanical, ×8 electrical)
2× DisplayPort 1.2, 1× 100/1000 Base-T RJ45 Ethernet Port
2× DisplayPort 1.2 + IP
4096 × 2160 @ 60 Hz,
4096 × 2160 @ 30 Hz,
3840 × 2160 @ 60 Hz,
3840 × 2160 @ 30 Hz
RTSP, RTP, SRT, MPEG-2 TS
two 3840 × 2160 @ 60 Hz,
four 3840 × 2160 @ 30 Hz,
eight 1920 × 1080 @ 60 Hz,
sixteen 1920 × 1080 @ 30 Hz,
or numerous SD channels
two 3840 × 2160 @ 60Hz,
four 3840 × 2160 @ 30Hz,
eight 1920 × 1080 @ 60Hz,
sixteen 1920 × 1080 @ 30Hz,
or numerous SD IP streams
L: 9.02 in / W: 0.75 in / H: 4.376 in
L: 22.9 cm / W: 1.91 cm / H: 11.1 cm
Class B: FCC, CE, RCM, VCCI, ICES-3, CSA, KC
®
10 IoT, Windows
®
Server
PCIe ×16 2.0
ATX
8 GB
—
H.264
*
Matrox Display Wall – User Guide 63
® ®
Server
®
2008 R2,
®
®
