Installing multiple cards

Your chassis model may support the installation of multiple Matrox cards in your system. For
information on validated platforms, contact your Matrox representative or see the Matrox web site
(www.matrox.com/graphics).
WARNING:
cards, always insert your card as straight as
possible into the slot. Don't rock the card
from side to side. If you meet resistance,
don't force the card into the slot.

Interconnecting multiple cards (Framelock)

Mura MPX Series, C900, and C680 only – If you have multiple Mura MPX output cards or
multiple C900 or C680 graphics cards installed in your system, you can synchronize the
frame rate of all your outputs by interconnecting your cards with a ribbon cable.
Mura MPX Series – Attach the ribbon cable
to the connector labeled
the connector labeled
Depending on the length needed, use either
the long or short ribbon cable included with
your product.
Repeat this for every card installed.
C900 and C680 – You can interconnect either two C900 graphics cards or two C680 graphics
cards.
Attach the ribbon cable to the connector
labeled
connector labeled
graphics card.
* Matrox C900 and C680 – Ribbon cable sold separately.
26 Matrox Display Wall – User Guide
To avoid damaging your
on one card to
Out
on the next card.
In
on one card and to the
GEN0
on the next
GEN0
Out In
GEN0 GEN1
*
