MURAIPXI-E4SF and MURAIPXI-E4SHF
Connection overview
Description of supported connections
Device connector
BNC
Network
(RJ-45)
BNC to BNC
cables
Description
If your video device has a BNC connector, attach your BNC cable to
your Matrox card. Connect the other end of the cable to your video
device.
If your video device streams to an IP network, connect a network
cable to your Matrox card. Your video device must stream using an
RTSP, RTP, SRT, or MPEG-2 TS protocol.
Network
cable
(RJ-45)
Matrox Display Wall – User Guide 35
