C680
This section explains how to connect your output devices (monitors) to your C680 card.
Connection overview
Description of supported connections.
Device connector
DisplayPort
HDMI
DVI
* Only active adapters (sold separately) are supported. Passive adapters aren't supported.
Description
If your monitor has a DisplayPort connector, attach your mini
DisplayPort to DisplayPort adapter to the mini DisplayPort connector
on your Matrox card. Connect the other end of the cable to your
monitor.
If your monitor has an HDMI connector, use a mini DisplayPort to
*
HDMI adapter (active
DisplayPort connector on your Matrox card. Connect the other end
of the cable to your monitor.
If your monitor has a DVI connector, use a mini DisplayPort to DVI
*
adapter (active
) to connect your monitor cable to the mini
DisplayPort connector on your Matrox card. Connect the other end
of the cable to your monitor.
Monitor connector
(Mini DisplayPort)
) to connect your monitor cable to the mini
Matrox Display Wall – User Guide 49
