Connecting your Mura IPX Series display
card
This section describes how to connect your Mura IPX Series 4K IP Decode and Display card.
Note: To make sure your cables are securely attached to your Matrox cards, use a cable retention
bracket. To purchase a cable retention bracket, contact your Matrox representative. For more
information,
MURAIPXO-D4LF • MURAIPXO-D4LHF
Note: Audio output is supported only on the DisplayPort connector labeled
Series display card.
Connection overview
Desciption of supported connections
Device connector
DisplayPort
DVI
32 Matrox Display Wall – User Guide
see "Appendix C – Matrox secure cable solution", page
Mini DisplayPort to
DisplayPort cables
Description
If your monitor has a DisplayPort connector, attach your mini
DisplayPort to DisplayPort cable to your Matrox card. Connect the
other end of the cable to your monitor.
If your monitor has a DVI connector, use a mini DisplayPort to DVI
adapter (active
Matrox card. Connect your monitor to the DVI connector on your
adapter.
Network cable
(RJ-45)
*
) to connect to the mini DisplayPort connector on your
87.
of your Mura IPX
