Description of cable
Cable
Input
Description of supported connections
Connector
Composite (RCA)
Composite (BNC)
S-video
46 Matrox Display Wall – User Guide
Description
Mura MPX-V16 or MPX-V8 cards use DVI to BNC cables to connect
to input devices.
Description
If your video device has an RCA composite connector, use a BNC to
Composite (RCA) adapter to connect to the
cable. Connect your video device to the composite connector on your
adapter.
If your video device has a BNC composite connector, connect the
composite cable directly to the
If your video device has an S-video connector, use a BNC to S-video
adapter to connect to the
Connect your video device to the S-video connector on your adapter.
connector on your input
Y
connector on your input cable.
Y
and
connectors on your input cable.
Y
C
