FreeFlight 2101 I/O Approach Plus GPS Navigation System
Position and Speed
ITEM
DESIGNATOR
k
Where:
a bb cc.cccc Current Latitude N or S (a), degrees (bb), minutes (cc.cccc)
d eee ff.ffff
ggg.g
Altitude
ITEM
DESIGNATOR
l
Where:
aaaaa.a
bbbbb.b
ccccc.c
Track
ITEM
DESIGNATOR
m
Where:
aaa.aa
bbb.bb
cdd.ddddd
efff.ff
Vertical Navigation
ITEM
DESIGNATOR
n
Where:
abbbb.b
cdddd.d
efffff.ff
gh
Page B-14
INFORMATION
Position and Speed
Current Longitude E or W (d), degrees (eee), minutes (ff.fff)
Ground Speed in knots
INFORMATION
Altitude (GPS, Pressure, and
Barometric)
GPS computed altitude
Pressure altitude
Barometric altitude
INFORMATION
Track (Magnetic, Desired,
Cross-Track Error, and Track
Angle Error
Magnetic Track in degrees
Desired Track in degrees
Cross Track Error L or R (c), nautical miles (dd.ddddd)
Track Angle Error L or R (e), degrees (fff.ff)
INFORMATION
Vertical Navigation (Actual,
Desired, Vertical Error from
Profile, and Vertical Angle Error)
Actual VNAV + or - (a), feet/minute (bbbb.b)
Desired VNAV + or - (c), feet/minute (dddd.d)
Vertical Error + or - (e), feet (fffff.f)
Vertical Angle Error + or - (g), degrees (h)
ITEM FORMAT
a bb cc.cccc d eee ff.ffff ggg.g
ITEM FORMAT
aaaaa.a bbbbb.b ccccc.c
ITEM FORMAT
aaa.aa bbb.bb cdd.ddddd efff.ff
ITEM FORMAT
abbbb.b cdddd.d efffff.f ghh.hh
