FreeFlight 2101 I/O Approach Plus GPS Navigation System
1.5

ACCESSORIES NOT SUPPLIED

1.5.1

Installation

Circuit Breaker (required)
Analog CDI or HSI
External Annunciators
Notes:
1. Current certification guidelines (AC 20-138A) require an altitude input for A1 and A2 certification. The
FreeFlight 2101 I/O Approach Plus accepts a serial altitude input in addition to DADS and Synchro formats.
Additional equipment may be necessary to provide this serial altitude input.
2. TSO-C129 requires a navigation display to provide a navigation warning flag. The display on the 2101
I/O is not intended as the primary navigation display; however, NAV flag triggering capability is available
using digital and discrete outputs identified elsewhere in this document.
1.5.2

GPS Cable Requirements

The GPS antenna cable is to be supplied or fabricated by the installation agency to meet the following requirements:
Insertion Loss
DC Resistance
A "GPS Antenna Fail" message is displayed if resistance limitation is exceeded.
1.5.2.1 GPS Cable Lengths Greater Than 50 Feet
RG-393 is an acceptable cable for installations greater than 50 feet in length. An equivalent cable may be used,
but must meet the criteria listed above. An alternative to RG-393 is available from PIC Wire & Cable. The cable
is PIC P/N 33141 and the matching TNC connectors are PIC P/N 190308 and PIC P/N 190309 for both the
straight and right angle type. The PIC Wire & Cable address is:
PIC Wire & Cable
N63 W22619 Main Street
P.O. Box 330
Sussex, WI 53089
(800) 742-3191
Fax: (414) 246-0450
Page 1-8
* Required Annunciator — Other annunciators are optional
< 10 dB @ 1.575 GHz
Ω
< 1
2 A for 28 V installations
Dedicated or switched through relay
Message (MSG) * -- Amber
Waypoint Alert (WPT) * -- Green or Amber
HLD (HLD) * -- Green or White
Approach (APR) * -- Green or White
Approach Mode Active
Approach Enabled
Leg Change
Revision E
May 31, 2006
