C.2.9.8 ARINC 743 TAWS Output Parameters
PORT 1 (J2-16 and 23) – Software version 241F and later
PORT 2 (J2-58 and 57) – Software version 241F and later
LABEL PARAMETER
076 Altitude (MSL)
101 HDOP
102 VDOP
103 True Track
110 Latitude
111 Longitude
112 Ground Speed
125 UTC
130 Horiz. Integrity
136 Vert. FOM
147 Mag. Variation
165 Vertical Speed
166 N/S Velocity
174 E/W Velocity
247 Horiz. FOM
260 Date
273 Sensor Status
