3.2.2.6 Set Advisory Messages
Most message displays can be configured to one of the following settings:
Off
Disables display of the message
On
Enables display of the message when appropriate, but keeps messages in the queue until selected by
the user for display
Pop-Up Enables display of the message automatically when appropriate. The message may require pilot
acknowledgment to remove the message by pressing the MSG key, or it may be an auto Pop-up/Pop-
down message as indicated below.
Most messages will function according to the chosen settings for all phases of flight, except as noted in
Table 3-5 for Approaches. These user-selectable parameters will affect the timing for various message types.
Access the Installation Setup and follow these steps to change the configuration of the advisory messages:
1.
Rotate the small, inner selector knob to display
2.
Rotate the large, outer knob to sequence through each of the Advisory messages categories listed in
Tables 3-5 and 3-6.
3.
At each category, press
4.
Rotate the small, inner knob to change the setting.
5.
Press
Configurable
Parameter
WPT Arrival/Turn Adv
Lead Time
Pop-Up/Down Message
Display Time
Revision E
May 31, 2006
FreeFlight 2101 I/O Approach Plus GPS Navigation System
to cause the editable field to flash.
when the setting is correct.
Description
Sets the lead time for Message and
Annunciator advisory of aircraft arrival
at the Waypoint or Turn Anticipation
Point
Sets the time that an Auto
Pop-Up/Pop-down message is
displayed
Table 3-5 Approach Message Options
ADVISORY MESSAGES.
TURN OUTER KNOB
Available
Default
Settings
Setting
3 to 60 sec
1 to 9 sec
10 sec
3 sec
Page 3-9
