FreeFlight 2101 I/O Approach Plus Installation And Checkout Manual page 117

C.2.9.4 ARINC 429 GAMA Output Parameters
PORT 1 (J2-16 and 23) – Software version 241C and later
PORT 2 (J2-58 and 57) – All software versions
NOTE: The following ARINC 429 GAMA labels are transmitted only for ARINC 429 GAMA LO and
ARINC 429 GAMA HI selections.
LABEL PARAMETER
074 No. of Waypoints
113 Checksum
303 Waypoint Rec. Start
304 WPT ID (1-3)
305 WPT ID (4-6)
306 WPT Latitude
307 WPT Longitude
261 GPS Discrete Word 1
326 Latitude Deviation Scale Factor
327 Vertical Deviation Scale Factor
C.2.9.5 ARINC 429 VDL Output Parameters
PORT 1 (J2-16 and 23) – Software version 241C to 241G
PORT 2 (J2-58 and 57) – Software version 241C to 241G
NOTE: The following ARINC 429 labels are transmitted in a Burst at a minimum rate of 10 times/second for a
minimum of one second for ARINC 429 VDL LO* selection.
LABEL PARAMETER
033 TDS – SLS Tune
242 TDS – Airport/Station Id.
244 TDS – Station Id.
243 TDS – Procedure Selection
232 TDS – Airport Id.
* Only software version 241C to 241G.
Revision E
May 31, 2006
FreeFlight 2101 I/O Approach Plus GPS Navigation System
FORMAT
GAMA
GAMA
GAMA
GAMA
GAMA
GAMA
GAMA
GAMA
429 BNR
429 BNR
FORMAT
429 BNR
429 BNR
429 BNR
429 BNR
429 BNR
OUTPUT RATE
LO SPEED HI SPEED
Variable, sent at
5 WPT per second
200 ms 200 ms
200 ms 200 ms
200 ms 200 ms
OUTPUT RATE
Burst
Burst
Burst
Burst
Burst
Page C-13
