FreeFlight 2101 I/O Approach Plus GPS Navigation System
PINOUT BY PIN NUMBER
PIN TYPE
J2-50 OUT
J2-51 DISCRETE IN
J2-52 IN
J2-53 IN
J2-54 IN
J2-55 IN
J2-56 IN
J2-57 ARINC 419/429 OUT
J2-58 ARINC 419/429 OUT
J2-59 ARINC 419/429 IN
J2-60 ARINC 419/429 IN
J2-61 ARINC 419/429 IN
J2-62 ARINC 419/429 IN
J2-63 ARINC 419/429 IN
J2-64 ARINC 419/429 IN
J2-65 POWER IN
J2-66 POWER IN
* Reserved for future use.
Figure 2-2 FreeFlight 2101 I/O Approach Plus J2 Pin-out (continued)
Page 2-8
SIGNAL
AP DEVIATION (+RT/-LT)
OLEO
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
TX2B
TX2A
RX2B
RX2A
RX3A
RX3B
RX4B
RX4A
+ 28 VDC
+ 28 VDC
NOTE
J2-39 AP DEV +RT/-LT (C)
SEE APPENDIX C PARAGRAPH C.2.8
SEE APPENDIX C PARAGRAPH C.2.8
SEE TABLES 3-2 AND 3-3
SEE TABLES 3-2 AND 3-3
SEE TABLES 3-2 AND 3-3
SEE TABLES 3-2 AND 3-3
SEE TABLES 3-2 AND 3-3
SEE TABLES 3-2 AND 3-3
