FreeFlight 2101 I/O Approach Plus GPS Navigation System
Notes:
1.
Each of the three FreeFlight 2101 I/O Approach Plus synchros may be programmed to output one of the
angles listed below, in either SYNCHRO or SIN/COS format, and either offset by 180° or not:
OFF
HDG
THDG
DTK
TDTK
BRG
TBRG
TKE
DA
TKE-DA
DA-TKE
BRG-HDG :
To reset any of the synchro outputs:
1. Press
.
2. Rotate the small knob to select the output type to be changed.
3. Rotate the large knob to move to the phase field.
4. Rotate the small knob to change the phase to either +000 or +180.
5. Rotate the large knob to move to the format field.
6. Rotate the small knob to select the format type, either SYNCHRO or SIN/COS.
7. Press
to save the changes.
Page 3-4
:
No synchro output
:
Heading (Magnetic)
:
True Heading
:
Desired Track
:
True Desired Track
:
Bearing
:
True Bearing
:
Track Angle Error
:
Drift Angle
:
Track Angle Error - Drift Angle
:
Drift Angle - Track Angle Error
Bearing - Heading
Revision E
May 31, 2006
